Fish Passage Site 20400127

Coordinates (dec. deg.): 61.12561°, -149.78904°
Legal Description: S012N003W15
Region: South Central
Road Name: OUR ROAD

Datum: NAD83
Quad Name / ITM: Anchorage A-8
AWC Stream #: 247-60-10340-2018
Stream Name: Little Campbell Creek South Fork

Elevation:

Site Comments: CAMBELL CREEK WATERSHED, CULVERT AND POND ABOVE ROAD CROSSING

Survey Date: Sep 15, 2004

Survey ANC04-3A127

Observers: Dean Beers, Vic Stanculescu

Overall Fish Passage Rating: Red

Tidal: No
Backwatered: No

Step Pools:
Construction Year:


Comments: CAMBELL CREEK WATERSHED, CULVERT AND POND ABOVE ROAD CROSSING, NEW CULVERT

Culvert Measurements

ID: 1 Structure Type: Pipe-arch (Corrugated Metal) Fish Passage Rating:

Length(ft): 51.1
Inlet Type: Projecting
Outlet Type:
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.67
Condition Rating(1-5): 5
Approach Angle:
Sedimentation At Inlet:
Inlet Substrate:
Outlet Substrate:
InletOutlet
Width(ft):6.2
Height(ft):3.0
Apron Length(ft):
Water Depth(ft): 0.3
Rustline Height(ft):
Substrate Depth(ft):
Backwatered?:
Baffles Present: No
Embedded?: No
Outfall Height: 0.01
Outfall Type:
Constriction Ratio: 0.49
Culvert Gradient: 3.41%
Max Slope:
Max Slope Length:

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):
Stream Flow Stage:
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Upstream bank full 75.0 26.00
Upstream bank full 100.0 23.00
Upstream bed width 75.0 12.90
Upstream bed width 100.0 5.50
Upstream ordinary high water 75.0 13.40
Upstream ordinary high water 100.0 12.10

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
D/S Thalweg 94.91
D/S Tailcrest or 1st Thalweg 95.00
Max Pool Depth 95.10
OHW Left Bank 95.58
OHW Left Bank 95.82
U/S Thalweg 1 97.12
Outlet Invert 1 0.00 0.0 95.29
Road Elev 25.50 101.04
Inlet Culvert Invert 1 51.00 0.0 97.03

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Visual Observation, Ground (A)

Fish Observations

No fish observations occurred during this survey.
