Fish Passage Site 20300194

Coordinates (dec. deg.): 60.77184°, -148.84130°
Legal Description: S008N003E24
Region: South Central
Road Name: Portage Glacier Road

Datum: NAD83
Quad Name / ITM: Seward D-5
AWC Stream #:
Stream Name: Byron Creek

Elevation:

Site Comments: PORTAGE CREEK WATERSHED

Survey Date: Oct 05, 2004

Survey ANC04-4A194

Observers: Dean Beers, Vic Stanculescu

Overall Fish Passage Rating: Red

Tidal: No
Backwatered: No

Step Pools:
Construction Year:


Comments: PORTAGE CREEK WATERSHED

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated Metal) Fish Passage Rating:

Length(ft): 94.0
Inlet Type: Mitered
Outlet Type:
Corrugation Depth(in.): 1.0
Corrugation Width(in.): 3.0
Condition Rating(1-5): 4
Approach Angle:
Sedimentation At Inlet:
Inlet Substrate:
Outlet Substrate:
InletOutlet
Width(ft):11.5
Height(ft):11.5
Apron Length(ft):
Water Depth(ft): 1.5
Rustline Height(ft):4.2
Substrate Depth(ft):
Backwatered?:
Baffles Present: No
Embedded?: No
Outfall Height:
Outfall Type:
Constriction Ratio: 0.55
Culvert Gradient: 0.52%
Max Slope:
Max Slope Length:
ID: 2 Structure Type: Circular pipe (Corrugated Metal) Fish Passage Rating:

Length(ft): 94.0
Inlet Type: Mitered
Outlet Type:
Corrugation Depth(in.): 1.0
Corrugation Width(in.): 3.0
Condition Rating(1-5): 4
Approach Angle:
Sedimentation At Inlet:
Inlet Substrate:
Outlet Substrate:
InletOutlet
Width(ft):11.5
Height(ft):11.5
Apron Length(ft):
Water Depth(ft):
Rustline Height(ft):4.5
Substrate Depth(ft):
Backwatered?:
Baffles Present: No
Embedded?: No
Outfall Height:
Outfall Type:
Constriction Ratio: 0.55
Culvert Gradient: 0.14%
Max Slope:
Max Slope Length:

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):
Stream Flow Stage:
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Upstream bank full 75.0 55.00
Upstream bank full 100.0 80.00
Upstream bed width 75.0 38.10
Upstream bed width 100.0 27.50
Upstream bed width 125.0 26.60
Upstream bed width 150.0 30.00
Upstream ordinary high water 75.0 48.50
Upstream ordinary high water 100.0 42.20
Upstream ordinary high water 125.0 45.00
Upstream ordinary high water 150.0 32.30

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
D/S Tailcrest or 1st Thalweg 86.06
OHW Left Bank 88.02
OHW Left Bank 88.37
U/S Thalweg 1 90.88
U/S Thalweg 2 91.25
Outlet Invert 1 0.00 0.0 88.15
Outlet Invert 2 0.00 0.0 88.22
Road Elev 47.00 107.24
Inlet Culvert Invert 1 94.00 0.0 88.64
Inlet Culvert Invert 2 94.00 0.0 88.35

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Visual Observation, Ground (A)

Fish Observations

No fish observations occurred during this survey.

Questions or comments about this report can be directed to dfg.dsf.webmaster@alaska.gov
