Fish Passage Site 60401785

Coordinates (dec. deg.): 69.00706°, -148.82109°
Legal Description: U005S014E16
Region: Arctic
Road Name: TAPS Access Road

Datum: WGS84
Quad Name / ITM: Sagavanirktok A-4
AWC Stream #:
Stream Name: Clarke Lake

Elevation:

Site Comments: PLMP 92.36. - 122-APL-3

Survey Date: Aug 08, 2010

Survey EDS10-TAP02

Observers: Mark Eisenman, Justin Leon

Overall Fish Passage Rating: Green

Tidal: No
Backwatered: Yes

Step Pools: No
Construction Year:


Site Observations:

  1. Mechanical damage or joints parting
  2. Structural Problem

Comments: PLMP 92.36. This culvert connects two ponds together. For this reason no stream widths were taken. It is an old pipe and the outlet has begun to rip apart. The outlet is also rusted through. Fish swirls were seen during the survey and a fish was seen jumping as well.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated steel) Fish Passage Rating: Green

Length(ft): 68.1
Inlet Type: Projecting
Outlet Type: Projecting
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.5
Condition Rating(1-5): 2
Approach Angle: 0.0
Sedimentation At Inlet: Yes
Inlet Substrate: None
Outlet Substrate: Cobble
InletOutlet
Width(ft):2.0 2.1
Height(ft):2.1 1.5
Apron Length(ft):
Water Depth(ft): 1.29
Rustline Height(ft):1.8
Substrate Depth(ft):0.0 0.3
Backwatered?: Yes
Baffles Present: No
Embedded?: No
Outfall Height: 0.0
Outfall Type: At Stream Grade
Constriction Ratio:
Culvert Gradient: 0.35%
Max Slope:
Max Slope Length:
  Culvert Observations:
  1. Mechanical damage or joints parting
  2. Structural Problem

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:CobbleCobble
Subdominant:BoulderBoulder
Stream Slope(deg.):
Stream Flow Stage:High

No stream width data available.

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
Road Elev (Road Surface) 103.09
Outlet Invert (Substrate) 0.00 98.51
D/S Water Surface Elev (Water Surface) 0.00 99.80
Outlet Culvert Top (Top of Pipe) 0.00 99.97
U/S Water Surface Elev (Water Surface) 68.10 99.80
Inlet Culvert Invert (Bottom of Pipe) 68.10 98.27
Inlet Culvert Top (Top of Pipe) 681.00 100.22

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Minnow Trap (A) Trap Duration(h): 0.5
Channel Type: Main Channel (>50% of water flow)
Comments: Nothing was caught.

Gear Type: Minnow Trap (B) Trap Duration(h): 0.5
Channel Type: Main Channel (>50% of water flow)
Comments: Nothing was caught.

Gear Type: Visual Observation, Ground (C)
Comments: Fish observed jumping and swirling in lake U/S.

Fish Observations

Species: general fish observation, no species information Life History: Not Recorded
Total Fish Observed: 1 Fish Measured: Fork Lengths (mm) Min: Max: Mean:
Collected/Observed by Gear Type: Upstream Visual Observation, Ground (1)

Species: no fish collected or observed Life History: Not Applicable
Total Fish Observed: 0 Fish Measured: Fork Lengths (mm) Min: Max: Mean:
Collected/Observed by Gear Type: Downstream Minnow Trap (0)  Upstream Minnow Trap (0)
