Fish Passage Improvement site 50101574

Fish Passage Site 50101574

Coordinates (dec. deg.): 64.69328°, -164.25788°
Legal Description: K009S028W22
Region: Arctic
Road Name: Council Road

Datum: NAD83
Quad Name / ITM: Solomon C-5
AWC Stream #:
Stream Name: Unnamed

Elevation:

Site Comments: Mile 45.7

Survey Date: Jul 05, 2006

Survey SEW05-COR19

site photos

Project Supervisor: Dave Ryland,
Observers: Dave Ryland, Kyle Negri

Overall Fish Passage Rating: Red

Tidal: No
Backwatered: No

Step Pools: No
Construction Year:

Site Observations:

Culvert gradient red

Comments: Additional 48" overflow pipe not surveyed. Snow & ice in channel during survey.

Culvert Measurements

ID: 1

Structure Type: Circular pipe (Corrugated steel)

Fish Passage Rating: Red

Length(ft): 78.3

Inlet Type: Flush

Outlet Type: Flush

Corrugation Depth(in.): 0.5

Corrugation Width(in.): 2.75

Condition Rating(1-5): 3

Approach Angle: 19.0

Sedimentation At Inlet:

Inlet Substrate: None

Outlet Substrate: None

	Inlet	Outlet
Width(ft):	3.1	2.8
Height(ft):	3.0	3.0
Apron Length(ft):
Water Depth(ft):		0.56
Rustline Height(ft):	0.8
Substrate Depth(ft):	0.0	0.0

Backwatered?: No

Baffles Present: No

Embedded?: No

Embedded Depth(ft): 0.0

Outfall Height: 0.0

Outfall Type: At Stream Grade

Constriction Ratio: 0.89

Culvert Gradient: 4.38%

Max Slope:

Max Slope Length:

Comments: Water depth calculated from inv and TW elev

Culvert Observations:

Culvert gradient red

Stream Measurements

Stream Substrates	Upstream	Downstream
Dominant:	Gravel	Gravel
Subdominant:	Cobble	Cobble

Stream Slope(deg.):
Stream Flow Stage:

Stream Width Type	Distance From Crossing (ft)	Stream Width (ft)
Downstream ordinary high water
Downstream ordinary high water	50.0	6.80
Upstream bank full
Upstream bank full	75.0	4.80
Upstream bank full	100.0	5.00
Upstream bank full	125.0	4.60
Upstream bed width
Upstream ordinary high water
Upstream ordinary high water	75.0	3.80
Upstream ordinary high water	100.0	3.90
Upstream ordinary high water	125.0	2.70

Elevations

Locator ID	Culvert Number	River Distance (ft)¹	Distance From Crossing (ft)²	Relative Elevation (ft)
Outlet Pool Water Elev				90.37
Max Pool Depth				1.65
D/S Grade Ctrl (Thalweg)		0.00	118.0	84.10
D/S Grade Ctrl (Thalweg)		53.00	65.0	86.79
D/S Grade Ctrl (Thalweg)		68.00	50.0	87.59
D/S Tailcrest or 1st Thalweg		102.00	16.0	90.08
OHW (Outlet Tailcrest)		102.00	16.0	90.52
Bankfull		102.00	16.0	91.01
D/S Thalweg		113.00	5.0	1.65
Outlet Invert	1	118.00	0.0	89.81
Road Elev		157.00		104.82
Inlet Culvert Invert	1	196.00	0.0	93.24
U/S Grade Ctrl (Thalweg)		199.00	3.0	93.88
U/S Grade Ctrl (Thalweg)		212.00	16.0	95.22
U/S Grade Ctrl (Thalweg)		233.00	37.0	95.66
U/S Grade Ctrl (Thalweg)		265.00	69.0	96.87
U/S Grade Ctrl (Thalweg)		280.00	84.0	97.55
U/S Grade Ctrl (Thalweg)		306.00	110.0	98.86
U/S Grade Ctrl (Thalweg)		334.00	138.0	100.16

Notes:

River distance is measured continuously throughout the survey reach along the thalweg of the stream.
Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

No fish sampling occurred during this survey.

Fish Observations

No fish observations occurred during this survey.
