Fish Passage Site 40501755

Coordinates (dec. deg.): 65.14589°, -147.40065°
Legal Description: F004N002E29
Region: Interior
Road Name: Steese Highway

Datum: WGS84
Quad Name / ITM: Livengood A-1
AWC Stream #:
Stream Name: Ponds at 33 mile

Elevation:

Site Comments: Ponds at 33 mile

Survey Date: Jun 16, 2010

Survey EDS10-STS06

Observers: Mark Eisenman, Justin Leon

Overall Fish Passage Rating: Gray

Tidal: No
Backwatered: No

Step Pools: No
Construction Year:


Site Observations:

  1. Outfall height gray

Comments: Ponds both U/S and D/S. Observed fish jumping in D/S pond. Water levels at time of survey are low enough that the pipe is dry at both inlet and outlet. Outfall height is pipe invert to top of water downstream. If water levels were higher their might not be an outfall height.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated steel) Fish Passage Rating: Gray

Length(ft): 76.5
Inlet Type: Flared Inlet
Outlet Type: Flared Inlet
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.5
Condition Rating(1-5): 3
Approach Angle: 16.0
Sedimentation At Inlet: Yes
Inlet Substrate: None
Outlet Substrate: None
InletOutlet
Width(ft):2.0 2.0
Height(ft):2.0 2.0
Apron Length(ft):3.1 3.2
Water Depth(ft):0.0 0.0
Rustline Height(ft):0.4
Substrate Depth(ft):0.0 0.0
Backwatered?: No
Baffles Present: No
Embedded?: No
Outfall Height: 0.23
Outfall Type: Free Fall In To Pool
Constriction Ratio:
Culvert Gradient: 0.14%
Max Slope:
Max Slope Length:

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:OrganicOrganic
Subdominant:Silt/ClayGravel
Stream Slope(deg.):
Stream Flow Stage:Low

No stream width data available.

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
Road Elev 1 106.46
D/S Water Surface Elev (Water Surface at end of Apron.) 1 0.00 96.89
Misc. (End of Apron) 1 0.00 97.12
Outlet Invert (Bottom of Pipe) 1 3.00 96.96
Inlet Culvert Invert (Bottom of Pipe) 1 79.50 97.99
Misc. (End of Apron) 1 82.50 98.10
Misc. (Bottom of apron on substrate) 1 82.50 97.56
U/S Water Surface Elev (U/S Pond W/S) 1 85.50 97.16

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Minnow Trap (A) Trap Duration(h): 0.75
Channel Type: Main Channel (>50% of water flow)
Comments: Trap set U/S in pond. No fish caught or observed in U/S pond.

Gear Type: Minnow Trap (B) Trap Duration(h): 0.75
Channel Type: Main Channel (>50% of water flow)
Comments: Trap set in pond D/S from culvert. Unidentified fish seen jumping in lower pond. No fish caught.

Fish Observations

Species: no fish collected or observed Life History: Not Applicable
Total Fish Observed: 0 Fish Measured: Fork Lengths (mm) Min: Max: Mean:
Collected/Observed by Gear Type: Downstream Minnow Trap (0)  Upstream Minnow Trap (0)
