Fish Passage Site 40501724

Coordinates (dec. deg.): 65.51407°, -148.57294°
Legal Description: F008N005W16
Region: Interior
Road Name: Livengood Road

Datum: WGS84
Quad Name / ITM: Livengood C-4
AWC Stream #:
Stream Name:

Elevation:

Site Comments: None

Survey Date: Jul 06, 2010

Survey EDS10-LIV04

Observers: Mark Eisenman, Justin Leon

Overall Fish Passage Rating: Green

Tidal: No
Backwatered: Yes

Step Pools: No
Construction Year:


Site Observations:

  1. Culvert gradient red
  2. Road bank erosion
  3. Road Fill (pushed off road by grader)
  4. Structural Problem
  5. Constriction ratio gray

Comments: Pipe is fully submerged at the outlet and almost fully submerged at the inlet. The inlet is bent and broken. It is missing its first couple feet of pipe. The outlet of this pipe has a lot of road bank erosion falling into it. Measurements may not be accurate because the pipe is submerged. The rust line height was not taken because the pipe was submerged. Stream widths were taken downstream because there is no clear upstream.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated steel) Fish Passage Rating: Green

Length(ft): 32.6
Inlet Type: Projecting
Outlet Type: Projecting
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.5
Condition Rating(1-5): 1
Approach Angle: 0.0
Sedimentation At Inlet: Yes
Inlet Substrate: None
Outlet Substrate: Gravel
InletOutlet
Width(ft):3.0 3.0
Height(ft):1.5 1.5
Apron Length(ft):
Water Depth(ft): 0.82
Rustline Height(ft):
Substrate Depth(ft):0.0 1.0
Backwatered?: Yes
Baffles Present: No
Embedded?: No
Outfall Height: 0.0
Outfall Type: At Stream Grade
Constriction Ratio: 0.57
Culvert Gradient: 1.69%
Max Slope:
Max Slope Length:
  Culvert Observations:
  1. Culvert gradient red
  2. Road bank erosion
  3. Road Fill (pushed off road by grader)
  4. Structural Problem
  5. Constriction ratio gray

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:Silt/ClayGravel
Subdominant:OrganicCobble
Stream Slope(deg.):
Stream Flow Stage:Medium
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Downstream ordinary high water 77.0 6.50
Downstream ordinary high water 96.0 5.30
Downstream ordinary high water 113.0 4.00

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
Road Elev (Road Surface) 99.90
D/S Thalweg (Thalweg) 0.00 96.56
D/S Water Surface Elev (Water Surface) 0.00 96.86
D/S Tailcrest or 1st Thalweg (Thalweg) 19.00 97.03
D/S Water Surface Elev (Water Surface) 19.00 97.45
D/S Water Surface Elev (Pool Surface) 25.00 97.47
Max Pool Depth (Substrate) 25.00 95.95
D/S Water Surface Elev (Water Surface) 26.00 97.45
Outlet Culvert Top (Top of Pipe) 26.00 97.22
Outlet Invert (Substrate) 26.00 96.63
Inlet Culvert Invert (Bottom of Pipe) 58.60 95.30
U/S Water Surface Elev (Water Surface) 58.60 97.45
Inlet Culvert Top (Top of Pipe) 58.60 97.77
U/S Headwater (Water Surface) 61.10 97.48
U/S Thalweg (Substrate) 61.10 95.54

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Minnow Trap (A) Trap Duration(h): 1.08
Channel Type: Main Channel (>50% of water flow)
Comments: No fish were caught.

Gear Type: Minnow Trap (B) Trap Duration(h): 1.08
Channel Type: Main Channel (>50% of water flow)
Comments: No fish were caught.

Fish Observations

Species: no fish collected or observed Life History: Not Applicable
Total Fish Observed: 0 Fish Measured: Fork Lengths (mm) Min: Max: Mean:
Collected/Observed by Gear Type: Downstream Minnow Trap (0)  Upstream Minnow Trap (0)
