Fish Passage Site 40501686

Coordinates (dec. deg.): 64.96050°, -147.61758°
Legal Description: F002N001E31
Region: Interior
Road Name: Elliott Highway

Datum: WGS84
Quad Name / ITM: Fairbanks D-2
AWC Stream #:
Stream Name: Goldstream Creek tributary

Elevation:

Site Comments: This culvert has a break in it. The break is a storm drain. Site runs under Steese Highway/Elliott Highway wiegh station and Elliott Highway.

Survey Date: Jun 10, 2010

Survey EDS10-ELH01

Observers: Mark Eisenman, Justin Leon

Overall Fish Passage Rating: Green

Tidal: No
Backwatered: No

Step Pools: No
Construction Year:


Site Observations:

  1. Sediment accumulation

Comments: Pipe is at an intersection and runs underneath both roads with a bend in the middle. The inlet-end of the pipe above the bend is 153' and the outlet-end section is 108'. This culvert has a break in it for a storm drain. There is heavy sedimentation throughout the pipes. There is rip-rap present at the inlet and outlet. Both upstream and downstream are ditches so the constriction ratio might not be used.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated steel) Fish Passage Rating: Green

Length(ft): 261.0
Inlet Type: Projecting
Outlet Type: Projecting
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.6
Condition Rating(1-5): 5
Approach Angle: 66.0
Sedimentation At Inlet: Yes
Inlet Substrate: Cobble
Outlet Substrate: Cobble
InletOutlet
Width(ft):5.0 5.0
Height(ft):4.8 5.0
Apron Length(ft):
Water Depth(ft): 1.44
Rustline Height(ft):0.97
Substrate Depth(ft):0.72 0.51
Backwatered?: No
Baffles Present: No
Embedded?: No
Outfall Height: 0.0
Outfall Type: At Stream Grade
Constriction Ratio: 0.99
Culvert Gradient: 0.11%
Max Slope:
Max Slope Length:


Comments: Might not use constriction ratio because both upstream and downstream are ditches. The inlet pipe is 153' and the outlet pipe is 108'.

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:Silt/ClaySilt/Clay
Subdominant:GravelGravel
Stream Slope(deg.):
Stream Flow Stage:Medium
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Downstream ordinary high water 33.0 5.76
Downstream ordinary high water 67.0 3.58
Downstream ordinary high water 107.0 5.82

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
Road Elev (Road Surface) 110.40
D/S Water Surface Elev (Water Surface) 0.00 99.70
D/S Tailcrest or 1st Thalweg (Substrate) 0.00 95.61
Outlet Invert (Substrate) 12.00 95.47
Top of Pipe Outlet (Top of Pipe) 12.00 95.96
D/S Water Surface Elev (Water Surface) 12.00 95.98
U/S Headwater (Water Surface) 273.00 96.10
Inlet Culvert Invert (Substrate) 273.00 95.74
Top of Pipe Inlet (Top of Pipe) 273.00 99.98
U/S Grade Ctrl (Thalweg) (Headwater Substrate) 279.00 95.67
U/S Headwater (Water Surface at Headwater) 279.00 96.49

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Minnow Trap (A) Trap Duration(h): 0.67
Channel Type: Main Channel (>50% of water flow)
Comments: No fish were caught.

Gear Type: Minnow Trap (B) Trap Duration(h): 0.67
Channel Type: Main Channel (>50% of water flow)
Comments: No fish were caught.

Fish Observations

Species: no fish collected or observed Life History: Not Applicable
Total Fish Observed: 0 Fish Measured: Fork Lengths (mm) Min: Max: Mean:
Collected/Observed by Gear Type: Downstream Minnow Trap (0)  Upstream Minnow Trap (0)
