Fish Passage Site 20300926

Coordinates (dec. deg.): 59.29771°, -151.71181°
Legal Description: S010S014W19
Region: South Central
Road Name: Port Graham

Datum: NAD83
Quad Name / ITM: Seldovia B-5
AWC Stream #:
Stream Name:

Elevation:

Site Comments: Location: Port Graham Stream: Channel comes down hillside, under the road, and into an open marsh. Substrate is soft muck. Upstream of the 75' location, the stream becomes subterranean.

Survey Date: Aug 18, 2004

Survey KPC04-1A107

Observers: Mary King, Pam Russell

Overall Fish Passage Rating: Red

Tidal: No
Backwatered: No

Step Pools:
Construction Year:


Comments: Location: Port Graham Stream: Channel comes down hillside, under the road, and into an open marsh. Substrate is soft muck. Upstream of the 75' location, the stream becomes subterranean. No stream flow (no measurements taken); stagnant water. Low vegetation on streamside. Culvert: No distinct tailcrest or thalweg...gradual elevation increase from the pool to the vegetation mat formed by the marsh. Pipe condition=5. Embedded-No. Note: Two culverts were located in this area and both were within the 400' error in the Port Graham waypoint data. Need to compare data with previous site evaluation to assure it is the same site!

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated Metal) Fish Passage Rating:

Length(ft): 30.24
Inlet Type: Projecting
Outlet Type:
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.67
Condition Rating(1-5):
Approach Angle:
Sedimentation At Inlet:
Inlet Substrate: Silt/Clay
Outlet Substrate: Silt/Clay
InletOutlet
Width(ft):1.5
Height(ft):1.5
Apron Length(ft):
Water Depth(ft): 0.52
Rustline Height(ft):0.03
Substrate Depth(ft):
Backwatered?:
Baffles Present: No
Embedded?: No
Outfall Height: -0.05
Outfall Type:
Constriction Ratio: 1.63
Culvert Gradient: 2.74%
Max Slope:
Max Slope Length:

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):
Stream Flow Stage:
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Upstream bank full 75.0 3.33
Upstream bed width 75.0 0.92
Upstream ordinary high water 75.0 0.92

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
D/S Thalweg 97.77
U/S Thalweg 1 98.86
OHW Left Bank 99.03
Outlet Culvert Top (Orange painted "X" on top of outlet, measured on 2nd corrugation.) 1 100.00
Max Pool Depth 0.00 5.0 98.65
Outlet Invert 1 5.00 0.0 98.46
Road Elev (Road surface.) 20.00 102.55
Inlet Culvert Invert 1 35.00 0.0 99.29

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

No fish sampling occurred during this survey.

Fish Observations

No fish observations occurred during this survey.
