Fish Passage Site 20300899

Coordinates (dec. deg.): 59.99104°, -151.49054°
Legal Description: S002S013W22
Region: South Central
Road Name: Oil Well Road

Datum: NAD83
Quad Name / ITM: Seldovia D-4
AWC Stream #:
Stream Name:

Elevation:

Site Comments: Location: Oilwell Rd. Good stream flow. Ponding upstream appears to have receded some with new pipe. Large boulders present downstream of outlet.

Survey Date: Jul 12, 2004

Survey KPC04-1A031

Observers: Mary King, Pam Russell

Overall Fish Passage Rating: Red

Tidal: No
Backwatered: No

Step Pools:
Construction Year:


Comments: Location: Oilwell Rd. Stream: Good stream flow. Ponding upstream appears to have receded some with new pipe. Large boulders present downstream of outlet. Flow measurements were done downstream of outlet; rocks were problematic Culvert: Pipe appears to be new since the 02 flood and is perched 2' at the outlet. Inlet is made of gabions forming a stair stepping headwall; the pipe extends beyond the wall 5'. Pipe condition=5. Embedded.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated Metal) Fish Passage Rating:

Length(ft): 64.74
Inlet Type: Headwall
Outlet Type:
Corrugation Depth(in.): 1.0
Corrugation Width(in.): 2.67
Condition Rating(1-5):
Approach Angle:
Sedimentation At Inlet:
Inlet Substrate:
Outlet Substrate:
InletOutlet
Width(ft):7.75
Height(ft):7.75
Apron Length(ft):
Water Depth(ft): 0.2
Rustline Height(ft):0.75
Substrate Depth(ft):
Backwatered?:
Baffles Present: No
Embedded?: No
Outfall Height: 1.95
Outfall Type:
Constriction Ratio: 0.56
Culvert Gradient: 0.37%
Max Slope:
Max Slope Length:


Comments: Culvert: Pipe appears to be new since the 02 flood and is perched 2' at the outlet. Inlet is made of gabions forming a stair stepping headwall; the pipe extends beyond the wall 5'. Pipe condition=5. Embedded.

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):
Stream Flow Stage:
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Upstream bank full 75.0 18.33
Upstream bank full 100.0 14.67
Upstream bank full 125.0 11.42
Upstream bank full 150.0 23.25
Upstream bed width 75.0 12.00
Upstream bed width 100.0 9.50
Upstream bed width 125.0 7.42
Upstream bed width 150.0 11.25
Upstream ordinary high water 75.0 15.00
Upstream ordinary high water 100.0 12.75
Upstream ordinary high water 125.0 9.17
Upstream ordinary high water 150.0 18.42

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
D/S Tailcrest or 1st Thalweg 89.38
OHW Left Bank 89.54
OHW Left Bank 90.05
D/S Thalweg 88.96
U/S Thalweg 1 92.48
Outlet Culvert Top (Orange spray painted "x" on top of outlet pipe ("X" over last seam before end of pipe).) 1 100.00
Max Pool Depth 0.00 5.0 89.19
Outlet Invert 1 5.00 0.0 91.80
Road Elev (Road surface.) 37.00 111.06
Inlet Culvert Invert 1 69.00 0.0 92.04

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

No fish sampling occurred during this survey.

Fish Observations

No fish observations occurred during this survey.
